storage tank design and drafting course
storage Tank Design
Design and Drafting Basics of StorageTank
https://3d-labs.com/product/design-and-drafting-basics-of-storage-tank/
Storage tanks are containers that hold liquids, compressed gases (gas tank) or mediums
used for the short- or long-term storage of heat or cold. This chapter contains information
about aboveground tanks, with special reference to tanks made of carbon steel materials.
Storage tanks are available in many shapes: vertical and horizontal cylindrical;
open top and closed top; flat bottom, cone bottom, slope bottom and dish bottom.
Large tanks tend to be vertical cylindrical, to easier withstand hydraulic &
hydrostatically induced pressure of contained liquid. Most container tanks for
handling liquids during transportation are designed to handle varying degrees
of pressure.
